TI-T3-AW1 Wireless Load Cell Weighing Indicator by Taj Instruments
Welcome to the future of industrial weighing technology. At Taj Instruments, we are proud to introduce the TI-T3-AW1 Wireless Load Cell Weighing Indicator, a revolutionary solution designed to eliminate the complexities of traditional, wired weighing systems. Whether you are managing a warehouse, operating a heavy industrial plant, or overseeing livestock logistics, our wireless technology provides the freedom, reliability, and precision you need to optimize your workflow. By removing the physical tether between the weighing platform and the display, we have effectively mitigated the most common issues in the industry—cable damage, signal interference, and installation limitations.
The TI-T3-AW1 is not just an indicator; it is a sophisticated industrial weighing controller that leverages advanced 2.4GHz frequency hopping technology to ensure secure and stable data transmission. Engineered for environments where reliability is non-negotiable, this system offers a robust wireless range of up to 20 meters in open areas, making it the perfect choice for moving platforms, long-distance weighing, or facilities where cable maintenance has historically been a significant operational cost. With the TI-T3-AW1, you are investing in a smarter, cleaner, and more efficient weighing infrastructure.
Key Features of the TI-T3-AW1
- Wireless Freedom: Eliminates the need for long, vulnerable load cell cables between the platform and indicator.
- Advanced Connectivity: Utilizes 2.4GHz frequency hopping technology to prevent signal interference and ensure data integrity.
- High Capacity: Supports 1–4 load cells (350Ω each), making it versatile for various scale sizes.
- Intelligent Display: Features a high-visibility 6-digit Green LED display that is easy to read in diverse lighting conditions.
- Extended Battery Life: Equipped with a 6V/4Ah rechargeable battery providing approximately 40 hours of backup.
- Versatile Functions: Includes built-in support for accumulation, counting mode, and animal weighing modes.
- Connectivity Options: Comes standard with an RS232 communication port for easy integration with printers and PCs.
- Robust Design: Housed in an Industrial ABS/Metal casing built to withstand the rigors of heavy-duty industrial use.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | TI-T3-AW1 |
| Accuracy Class | OIML Class III |
| Display Type | 6 Digit Green LED Display |
| Status Indicators | 13 Indication LEDs |
| Wireless Frequency | 2.4GHz |
| Operating Range | ≥20m (without obstruction) |
| Communication Port | RS232 (Optional Bluetooth 2.0) |
| Power Supply | AC 220V + Rechargeable Battery |
| Battery Backup | Approx. 40 Hours |
| Load Cell Support | 1–4 x 350Ω Load Cells |
| Operating Temp | 0°C to 40°C |
Applications & Industries
The versatility of the TI-T3-AW1 makes it an indispensable asset across a wide range of industrial applications. Because the system is wireless, it is particularly suited for environments where equipment needs to be moved frequently or where cables would typically pose a safety hazard or be susceptible to damage.
- Industrial Platform Scales: Ideal for high-traffic warehouse floors and manufacturing assembly lines.
- Mobile Weighing Systems: Perfect for mobile trolleys and platforms that need to move throughout a large facility.
- Animal & Livestock Weighing: The specialized Animal Weighing mode provides stable readings even when the subjects are moving.
- On-board Vehicle Weighing: Excellent for vehicle scales where physical connections are difficult to maintain.
- Chemical & Steel Industries: The robust construction ensures longevity in harsh, high-wear environments.
- Long-Distance Weighing: Provides accurate readings even when the operator needs to be distanced from the scale base.
Why Choose the TI-T3-AW1?
Choosing the right weighing equipment is a critical business decision. The TI-T3-AW1 offers significant advantages over traditional wired systems that go beyond just convenience:
- Reduced Maintenance Costs: By removing the cable, you eliminate the single most common point of failure in industrial scales—the load cell wire.
- Enhanced Safety: A cleaner floor space without wires reduces trip hazards and accidental damage to equipment.
- Superior Interference Rejection: Our frequency hopping technology ensures that your data remains accurate even in environments with multiple wireless devices.
- Easy Setup: Installation is simplified, allowing for rapid deployment and easy shifting of the platform as your business needs evolve.
Operating Features and Functionality
The TI-T3-AW1 is designed with the user in mind. The interface is intuitive, allowing operators to switch between modes with minimal training. The Counting Mode allows for precise inventory management by calculating the number of items based on weight, while the Accumulation Function enables users to sum multiple weighing events, which is essential for batch processing and loading operations. Furthermore, the Zero and Tare functions allow for rapid resetting of the scale, ensuring that you only measure the net weight of your materials. The inclusion of 13 status indicators provides real-time feedback on the scale's state, including battery levels, stable readings, and weight units (Kg/Lb), providing the operator with total control over every weighing transaction.
Durability and Build Quality
At Taj Instruments, we understand the harsh environments in which our scales operate. The TI-T3-AW1 indicator is constructed from high-grade industrial materials. The indicator housing is built from durable ABS plastic and metal, designed to protect the internal electronics from dust, moisture, and minor impacts. The weighing platforms paired with this indicator are crafted with heavy-duty structural integrity, ensuring they can handle the daily stresses of industrial loading and unloading. Whether it is a dusty warehouse floor or a high-traffic manufacturing environment, the TI-T3-AW1 is built to last.
Power and Energy Efficiency
We know that downtime is not an option. The TI-T3-AW1 is equipped with a dual power system. It operates on a standard AC 220V power supply while simultaneously maintaining an internal 6V/4Ah rechargeable battery. In the event of a power outage or when working in remote areas without access to electrical outlets, the unit provides approximately 40 hours of continuous operation. This makes it a truly portable, reliable solution for demanding business workflows.
Why Buy From Taj Instruments?
Taj Instruments is a leader in weighing technology, committed to quality and innovation. As an ISO 9001:2015 Certified Company, we adhere to strict quality control measures to ensure that every product leaving our facility meets global standards. We are not just a manufacturer; we are your partners in precision. When you choose Taj Instruments, you get more than just a product; you get the support of a dedicated technical team, comprehensive after-sales service, and the assurance of working with a brand that values integrity and performance above all else. Transform your facility's efficiency today with the TI-T3-AW1. Contact us for bulk orders, OEM inquiries, or technical support, and experience the Taj Instruments difference.
