Model 70210 Tank Weighing Scale by Taj Instruments
Welcome to the pinnacle of industrial weighing precision with the Model 70210 Tank Weighing Scale, proudly manufactured by Taj Instruments. Designed for the most demanding industrial environments, this advanced weighing system provides unparalleled accuracy and reliability for monitoring liquids, powders, chemicals, oils, and various bulk materials. Whether you are managing storage tanks, hoppers, or silos, our system ensures that you have real-time, precise data to optimize your production processes, batching, and inventory management.
At Taj Instruments, we understand the complexities of industrial automation. That is why our tank weighing system is engineered to integrate seamlessly into your existing workflows, utilizing high-quality Double Ended Shear Beam Load Cells that are built to last. This system is not just a tool; it is an essential component for process control, mixing, and automation across a wide spectrum of industries in India and beyond.
Key Features of the Model 70210
- Versatile Capacity: Offers a wide range of weighing capacities from 2.5 Ton to 100 Tonf, making it suitable for both small and large-scale storage vessels.
- Robust Load Cell Design: Features high-precision, strain gauge-based Double Ended Shear Beam load cells that ensure consistent, repeatable measurements.
- Environmentally Protected: Built with an IP68 protection class, ensuring the system remains functional even in harsh, dusty, or wet industrial environments.
- Superior Material Quality: Constructed with Electroless Nickel Plated Tool Steel, providing excellent resistance to corrosion and mechanical wear.
- Easy Installation: Designed for straightforward integration with optional Weigh Module Hardware-WM-II, simplifying the setup for tanks, hoppers, and silos.
- High Accuracy: Engineered for extreme precision, minimizing measurement errors and maximizing product consistency.
- Long-Distance Reliability: Each unit comes with a minimum 10-meter cable, allowing for flexible placement of the indicator relative to the tank.
- Industry Compliance: Proudly manufactured by an ISO 9001:2015 certified company, adhering to stringent quality control standards.
Technical Specifications
The Model 70210 is built to deliver consistent performance under varying industrial conditions. Below are the core technical specifications for our load cell:
| Specification | Details |
|---|---|
| Standard Capacities (Tf) | 2.5, 5, 10, 20, 25, 30, 50, 75, 100 |
| Excitation Voltage | 10 VDC - Maximum 15 VDC |
| Nominal Output | 3.0 mV/V |
| Non-Linearity | < ± 0.025 % FSO |
| Hysteresis | < ± 0.02 % FSO |
| Non-Repeatability | < ± 0.01 % FSO |
| Creep (30 minutes) | < ± 0.03 % FSO |
| Zero Balance | ± 1.0 % FSO |
| Input Resistance | 770 ± 20.0 Ohms |
| Output Resistance | 700 ± 7.0 Ohms |
| Environmental Protection | IP68 Class |
Applications & Industries
The versatility of the Model 70210 Tank Weighing Scale makes it an ideal solution for a diverse array of sectors. By providing accurate, real-time data, our system enables companies to automate their processes and reduce material waste significantly. Industries that rely on our technology include:
- Chemical Industry: Precision monitoring of raw materials and chemical mixtures for safe processing.
- Food & Beverage: Ensuring exact batching and mixing of ingredients for consistent quality.
- Pharmaceuticals: Maintaining strict weighing accuracy for highly sensitive chemical formulations.
- Paint Manufacturing: Managing the precise composition of pigments, solvents, and binders.
- Cement & Construction: Monitoring bulk storage levels in silos and hoppers for efficient supply chain management.
- Oil & Petroleum: Reliable measurement of liquid volumes in tanks to ensure accurate inventory and distribution.
- Water Treatment: Continuous monitoring of chemical additives and storage levels in treatment plants.
- Agro & Feed Industry: Efficiently managing bulk feed storage and distribution processes.
Why Choose This Product
Choosing Taj Instruments means investing in quality, reliability, and precision. Our tank weighing systems are trusted by industries across India for several compelling reasons:
- Increased Profitability: By reducing material loss and improving batching accuracy, our scales directly contribute to your bottom line.
- Seamless Integration: Designed to work harmoniously with existing PLC and SCADA systems for modern automation needs.
- Durability: Our Electroless Nickel Plated Tool Steel construction ensures the scale survives the toughest industrial conditions.
- Expert Support: As a leading manufacturer, we provide excellent after-sales support and technical guidance.
- Proven Reliability: With thousands of successful installations, our systems are synonymous with performance.
Operating Features and System Components
The Model 70210 system is designed as a complete, integrated solution. The process begins with the tank mounted on high-precision load cells. These sensors detect the weight change and transmit an electronic signal to the digital indicator. This indicator, such as our TI-T3A12 model, displays the accurate weight in kg or tons, providing operators with clear, readable data. The system includes essential components such as the load cell itself, the mount assembly, a junction box, and all necessary cables and connectors. This holistic approach ensures that every part of the weighing loop is optimized for maximum signal integrity and accuracy.
Durability & Build Quality
Industrial environments are notoriously tough on electronic equipment. Moisture, dust, vibration, and temperature fluctuations can degrade performance over time. Our Model 70210 is specifically built to combat these challenges. The IP68-rated load cells are hermetically sealed against moisture, making them perfect for washdown areas or outdoor storage. The use of high-grade tool steel ensures that the mechanical structure can handle heavy static loads while remaining responsive enough to detect even minor weight fluctuations. When you install a Taj Instruments weighing scale, you are installing a system that is built to last for years of continuous operation.
Why Buy From Taj Instruments
Taj Instruments has established itself as a cornerstone of the Indian weighing industry. Our commitment to innovation is reflected in our ISO 9001:2015 certification and our adherence to international quality standards. We do not just sell products; we provide comprehensive weighing solutions tailored to your unique operational requirements. From initial consultation to installation and long-term maintenance, our team of experts is dedicated to your success. Our reputation is built on trust, precision, and our unwavering focus on customer satisfaction. When you choose the Model 70210, you are choosing a product backed by a legacy of excellence and a future of technological advancement.
Ready to upgrade your industrial weighing capabilities? Contact Taj Instruments today and speak with our technical team to find the perfect configuration for your facility. Experience the difference that high-precision, reliable weighing can make in your daily operations. Visit our website or call us at 9328511234 to get started.
